FPGA MEETS CPU – USE YOUR IMAGINATION

The LOGI Pi is an FPGA development platform that has been optimized for use with the Raspberry Pi. The LOGI Pi/Raspberry Pi combination was designed with key design attributes in mind including ease of use, maximum expansion capability and low cost to performance ratio.  The LOGI Pi creates a powerful and versatile digital canvas for users to create their imaginative digital designs.

SW/DRIVERS SUPPORT – DON’T GET BOGGED DOWN IN THE MUD

The LOGI Team has developed software and drivers that make it easy for users to communicate between the FPGA and the Raspberry Pi.  APIs and Wrappers have been written that allow easy access to the FPGA custom hardware peripherals using the wishbone bus standard.  Applications can easily be written using C,C++ in conjunction or with python.  APIs for these languages allow easy to use communication with the FPGA.

APPLICATIONS – DON’T WAIT TO GET IT WORKING

The LOGI Team has created a number of applications for the LOGi-Pi including a bitcoin miner, machine vision and autonomous vehicle and robotic controllers.  All applications are open source and available on the LOGI repository.  An “App Store” (Free) application methodology has been developed that allows users to simply download the latest fully built applications and run them with no need to delve into building the HDL and source code.

CUSTOM HARDWARE

The LOGI Team is developing custom hardware modules to enable direct support for applications that they could not find an easy existing solution.   LOGI Hardware modules are designed using the widely used standards including Digilent Inc PMOD, Arduino Shield and high bandwidth modules using SATA connectors (For LVDS expansion only - SATA protocol not supported).  Existing LOGi modules include the LOGI Cam and the LOGI EDU.

FEATURES

• FPGA:  Spartan 6 LX9 – TQFP144 Package - XC6SLX9-2TQG144C

• Plug and play interfacing the Raspberry Pi

• Arduino Shield expansion allowing for more than 200 existing plug in hardware modules

• PMOD compatible headers allowing for more than 50 existing low cost hardware modules

• 4 layer optimized design to support maximum performance of high bandwidth applications

• Length tuned GPMC, SDRAM and LVDS signals for high performance applications

PERIPHERALS

• 2xPush buttons

• 2x DIP Switch

• 1x High bandwidth SATA connector expansion port (SATA protocol not supported)

• 32 FPGA IO through PMOD and Arduino headers

• 4x Digilent Inc. PMOD ports supporting 59+ plug and play hardware modules

• 1x Arduino Header supporting 200+ Arduino Shield modules

• Optional I2C, SPI access from the Raspberry Pi

• 10x length tuned LVDS pairs

• 32 MB SDRAM

RESOURCES

All LOGI Documentation

LOGI Pi Schematics

LOGI Pi User Manual

LOGI Pi Quick Start Guide

LOGI Projects

LOGI Repository

Purchase

The LOGI Boards are now being sold at element14, Farnell and Newark and MCM.
